Three Phase On Grid Solar Inverter 12KW Ip65

Product Categories

Shenzhen JinFuYuan Power. Co., Ltd

Contact Now

Name: Three Phase On Grid Solar Inverter 12KW Ip65
Brand: JFY TECH
Price: 1 USD

Brand Name : JFY TECH

Model Number : Suntree 12000TL

Certification : CE

Place of Origin : CHINA

MOQ : 20

Price : USD

Payment Terms : T/T

Supply Ability : 450

Delivery Time : 5-8 work days

Packaging Details : carton box

PV Input : 200-1000Vdc

AC Output : 400Vac

Rated Output Power : 12KW

Degree of protection : IP65

Contact Now

Three phase on grid solar inverter with 12KW

SUNTREE Series 5K-12KTL+

Three Phase String Inverter

Features

> Support double glass PV module

> LCD screen, multiple-function buttons, easy operation and maintenance

> Wide input voltage range, 250-1000Vdc

> Max. efficiency of 98.1% and Max. MPPT efficiency of 99.8%

> Diverse communication connection: RS232, RS485,WIFI and GPRS

> IP65 protection degree, natural cooling

Technical data	5000TL+	6000TL+	8000TL+	10000TL+	12000TL+
Input (DC Side)
Max. DC input power	6500W	7500W	9600W	12000W	14400W
Max. DC voltage	900Vdc		1000Vdc
Start voltage	200Vdc
MPPT voltage range	200-850Vdc		200-1000Vdc
Number of inputs	1	1	2	2	2
Number of MPPT	1	1	2	2	2
Max. input current	20A		2*20A
Output (AC Side)
Rated output power	5000W	6000W	8000W	10000W	12000W
Max. output power	6500VA	7500VA	9600VA	12000VA	14400VA
Rated output current	7.2A	8.7A	11.6A	14.4A	17.3A
Max. output current	7.9A	9.5A	12.7A	15.8A	19A
Rated output voltage	400Vac
Output voltage range	323-480Vac
Grid frequency range	50/60HZ+5
Power factor (cosφ )	0.8 (leading)-0.8 (lagging)
THDI	<3%
Efficiency
Max. efficiency	97.60%	97.80%	98.10%
Euro, efficiency	97.10%	97.30%	97.30%	97.50%	97.60%
MPPT efficiency	99.80%
Protections
Built-in protections	DC Reverse Polarity, Short Circuit, Output Over Current, Output Over Voltage, Insulation Resistance Monitoring,Residual Current Detection, Surge Protection, Anti-Island Protection, Over Temperature Protection
Lightning protection	DC Type \|\|/AC Type \|\|
General Data
Operating temperature	-25~+60°C
Noise	≤30dB (A)
Night power consumption	<2W
Electrical isolation	Transformerless
Cooling concept	Natural cooling
Degree of protection	IP65
Com munication :RS232/RS485/WiFi/4G	yes/opt/opt/opt
Dimension (WDH )	355190450mm
Weight	18kg
